Power X C10-10 10 Ton 10" Stroke Cylinder
FREE SHIPPING IN THE CONTINENTAL U.S.
- Single Acting with spring return
- Collar and base threads accommodate accessories and adapters.
- 3/8” NPTF high flow coupler with dust caps
- Exterior finish power painted and ANSI B30.1-compliant.
- Rod end saddle, available as an option (PX-ADTC-10)
POWER X C10-10 |
|
| Capacity | 10 Tons |
| Stroke | 10" |
| Oil Capacity | 22.65 cubic " |
| Collapsed Height | 13.75" |
| Extended Height | 23.88" |
| Outside Dia. | 2.25" |
| Collar Thread | 2-1/4" - 14" |
| Thread Length | 1.13" |
| Rod Dia. | 1.5" |
| Bore Dia. | 1.69" |
| Effective Area | 2.24 square" |
| Base Hole Thread | 1-1/4" - 11-1/2" NPT |
| Rod End Internal Thread | 1" - 8" |
| Weight | 14 Lbs |
