| ATTRIBUTE |
VALUE |
| Gravity-feed |
Less air; Better control/atomization & output |
| Transfer Rate |
HVLP for Higher Efficiency % |
| Spray Control |
Unique pattern/Optimal overlap/Low overspray |
| Spray Media |
Compatible with solvent & waterborne paints
|
| Operating Pressure |
29psi |
| Air Consumption (Avg.) |
9-10 cfm |
| Air Cap / Fluid Tip |
1-turn lock / 3-turn lock |
| Air Cap Capacity |
10 psi |
| Compressor Rqmt (Avg.) |
2-5HP |
| Air Hose (ID) |
6 - 8mm |
| Cup (ID) |
600ml Plastic Cup |
| Pattern (@ 4 - 7" distance)
|
9" to 12"/CENTER> |
| Gun |
Anodized Body & Internally-coated passages |
| Dimensions |
W x H: 7" x 5-3/4" |
| Net Weight |
.7lbs. |
