PBTCF161764 Truck Cross Flow Paint Booth
A large-format paint booth engineered for tractor trailers, commercial trucks, and oversized equipment. With a spacious 60-foot interior, durable galvanized steel construction, and a high-capacity exhaust system, this booth is designed for demanding commercial and industrial finishing applications.
Built for Trucks, Trailers, and Oversized Equipment
The PBTCF161764 Truck Cross Flow Paint Booth from Merchant 1 Manufacturing is designed for facilities that need the space and ventilation capacity to handle large vehicles and equipment. With a 16-foot-wide, 16-foot-tall, 60-foot-long interior, this booth accommodates a range of commercial vehicle refinishing, fleet maintenance, and industrial coating applications, subject to the dimensions and configuration of the equipment being finished.
Its cross flow ventilation design moves air through the booth toward the exhaust filtration system, helping manage airborne overspray during properly configured and operated finishing processes. The booth features a 42-inch exhaust fan powered by a 5 HP, three-phase motor, with a rated airflow of 25,600 CFM at 1/4-inch static pressure.
Constructed from durable 18-gauge G-90 galvanized steel, the PBTCF161764 is built for demanding commercial finishing environments. Seventeen 2' × 4' LED fixtures with glass provide work-area lighting, while the included intake and exhaust filter pads, manometer/draft gauge, hardware, and sealants support the booth installation.
Manufactured in Reidsville, North Carolina, Merchant 1 Manufacturing offers truck booth configurations in multiple sizes to suit different vehicle dimensions, facility layouts, and production needs. Custom sizing and additional equipment options are available through our sales team.
Product Specifications
| Model Number | PBTCF161764 |
| Booth Style | Truck Cross Flow Paint Booth |
| Inside Dimensions | 16' W × 16' H × 60' L |
| Outside Dimensions | 17' W × 16' 8" H × 64' L |
| Construction | 18-Gauge G-90 Galvanized Steel |
| Front Door Opening | 11' W × 15' H |
| Lighting | 17 × 2' × 4' LED fixtures with glass |
| Exhaust Fan | 42-Inch Fan |
| Motor | 5 HP, 3-Phase |
| Exhaust Airflow | 25,600 CFM at 1/4" Static Pressure |
| Filtration | 20" × 20" Intake and Exhaust Filter Pads |
| Included Accessories | Manometer/draft gauge, hardware, and sealants |
| Fire Suppression | Installer contacts provided for your area |
Key Features and Benefits
- Large-Format Interior: A 16' × 16' × 60' interior designed for large trucks, tractor trailers, and oversized equipment that fit within the booth's clearances and door opening.
- Cross Flow Ventilation: Designed to move air through the work area toward the exhaust filtration system.
- High-Capacity Exhaust: A 42-inch fan with a 5 HP, three-phase motor, rated at 25,600 CFM at 1/4-inch static pressure.
- Durable Galvanized Construction: Manufactured from 18-gauge G-90 galvanized steel.
- Extensive LED Lighting: Includes 17 2' × 4' LED fixtures with glass.
- Intake and Exhaust Filtration: Designed for 20" × 20" filter pads on both the intake and exhaust sides.
- Installation Accessories Included: Includes a manometer/draft gauge, hardware, and sealants.
- Custom Configurations Available: Multiple booth sizes and additional options are available to accommodate different vehicles, shop layouts, and operating requirements.
Available Options and Upgrades
Customize the PBTCF161764 to better suit your facility layout, electrical supply, and finishing requirements. Available options include:
- Single-phase motor option
- 42" diameter × 8' long exhaust ductwork package
- Bright white powder-coated finish for the complete booth
- Control panel for lights and fan
- High-end VFD control panel with UL-listed components
- VFD options for single-phase to three-phase or three-phase to three-phase applications, subject to equipment compatibility
- Drive-through doors
Planning a truck booth installation? Contact our sales team for help with sizing, configuration, available options, and a complete quote for your project.
Customer Responsibilities and Installation
- Delivery Offloading: The customer is responsible for unloading the delivery truck. A forklift is required to unload the crate; a forklift with 60-inch forks is recommended.
- Construction and Installation: Booth assembly and installation, including electrical work, are the customer's responsibility. Installation instructions are provided, and our in-house design team is available to answer installation questions.
- Electrical Work: All electrical installation for the paint booth and any associated air makeup unit must be performed by a licensed electrician familiar with applicable national, state, and local electrical codes and regulations.
- Permits and Fire Protection: The customer is responsible for determining and obtaining required local permits and arranging fire suppression where required. Merchant 1 Manufacturing can provide contacts for fire suppression system installers in your area.
- Site Preparation: Confirm adequate building height, floor space, access, utilities, and delivery access for the booth's overall dimensions before ordering.
Safety and code note: Confirm booth suitability, ventilation design, electrical installation, and fire-protection requirements with qualified professionals and the local authority having jurisdiction before installation and use. Component certifications do not by themselves establish that the complete booth installation meets every applicable code or regulatory requirement.
